High speed automatic filling machine ( 2 lines 4 fillers )
This series machine is a new-designed that we make it on placing the old Turnplate Feeding on
one side. Dual auger filling within double lines main-assist fillers and the originated Feeding
system can keep the high-precision and take off the tiring cleaning of the turntable. It can do
the accurate weighing & filling work, and also could combined with other machines to buildup a
whole can-packing production line. This machine could be used in filling milk powder, albumen
powder, condiment, dextrose, rice flour, cocoa powder, solid drink, and so on.
1. Double lines dual fillers, Main & Assist filling to keep work in high-precision.
2. Can-up and horizontal transmitting is controlled by servo and pneumatic system, be more accurate, more speed.
3. Servo motor and servo driver control the screw, keep stable and accurate.
4. Stainless steel structure, Split hopper with polishing inner-out make it to cleaned easily.
5. PLC & touch screen make it be easy of operation.
6. Fast-respond weighing system make the strongpoint to real.
7.The handwheel make the exchange of different filings to be easily.
8. Dust-collecting cover meet the pipeline and protect environment to pollution.
9. Horizontal straight design make the machine in little area.
10.Settled screw setup make no metal pollution in producing.
11.Process: can-into → can-up → vibration → filling → vibration → vibration → weighing & tracing → reinforce → weight checking → Can-out
12.With whole system central control system.
Dosing mode | Double lines dual filler filling with online weighing |
Filling Weight | 100 – 2000g |
Container Size | Φ60-135mm; H 60-260mm |
Filling Accuracy | 100-500g, ≤±1g; ≥500g,≤±2g |
Filling Speed | Above 100 cans/min(#502),Above 120 cans/min(#300 ~ #401) |
Power Supply | 3P AC208-415V 50/60Hz |
Total Power | 5.1 kw |
Total Weight | 650kg |
Air Supply | 6kg/cm 0.3cbm/min |
Overall Dimension | 2920x1400x2330mm |
Hopper Volume | 85L(Main) 45L (Assist) |
Tandy machinery manufactures mixing
equipments, packaging equipments, conveying
equipments, checking weighers, industrial dust
collectors, batching systems. Many customers
use and recognize our products. It is with CE certification.
